3 cuotas | Especificaciones | |
| Factory #Diamond CP | SPECIFICATION |
| Form Factor (Midi, Micro, Mini ITX, Full) | Midi ATX Tower |
| Chassis | SPCC : 0.5mm |
| PSU Form Factor | Bottom/ATX |
| M/B Form Factor | ATX、M-ATX、ITX |
| Front Panel | ABS |
| Top Panel | metal cover |
| Branding | Box GameMax standard |
| Unit | 1 |
| Side Panel | Left Tempered Glass |
| Right | metal cover |
| External Drive Bay(s) | 5.25" (ODD) *0 |
| 3.5" | *0 |
| Internal Drive Bay(s) | 3.5" (HDD) *2 |
| 2.5" (SSD) | *2 |
| I/O CONFIG | Buttons *2 |
| USB2.0 Port(s) | *1 |
| USB3.0 Port(s) USB3.1 GEN1 | *1 |
| HD Audio Support | *1 |
| Card Reader (Support) | *0 |
| P-Lock | *0 |
| RGB Controller | *1 Build-in Master FAN |
| Remote (IR or RF) | *Top RGB switch |
| Cooling Fan Support | Front 3x120mm,2x140mm(Fan optional) |
| Top | 2x120mm(ARGB Fan Included),2x140mm (Fan optional) |
| Rear | 1x120mm (ARGB Fan Included) |
| MB Plate | 1x 140mm Turbo Fan (Included) |
| PSU Cover | 2x120mm (Fan optional) |
| Water Cooling Support (Radiator Size) | Front 120mm, 140mm,240mm,280mm |
| Top | 120mm, 240mm |
| Rear | 120mm*1 |
| Dust Cover | Bottom and top cover with dust filter |
| Slots | *7 |
| Carton & Logo | GAMEMAX |
| Dimensions | Chassis (L)360*(W)210*(H)440mm |
| Full Case (inc Fascia) | (L)421*(W)210*（H)460mm |
| Carton | (L)*(W)*（H)mm |
| Net Weight (Kg) | 4.4kgs |
| Gross Weight (Kg) | 5.3kgs |
| VGA Card Length | up to 340mm |
| CPU Cooler Height | 170mm |
| Cable Management Depth | 22mm |
| Identificacion | |
| Marca | gamemax |
| Part number | DIAMOND CP BK |
Especificaciones provistas por el fabricante o el distribuidor. Pueden contener errores u omisiones y variar sin previo aviso.
