SPECIFICATIONS
USB ports N/A
DYNAMIC REFRESH RATE
TECHNOLOGY Adaptive-Sync
ACTIVATED RANGE 48~180Hz
Adobe RGB / DCI-P3 / sRGB 91% / 88% / 118%
Dimension (W x D x H)
541.9 x 231.9 x 424.3 mm
541.9 x 59.7 x 322.3 mm (Without
stand)
Carton Dimension (W X D X H) 622 x 160 x 409 mm (WW carton)
637 x 174 x 433 mm (JP carton)
Panel Size 23.8” (60cm)
Aspect ratio 16:9
Panel Resolution 1920 x 1080 (FHD)
Pixel Pitch (H x V) 0.2745(H) x 0.2745(V)
Refresh Rate 180Hz
Response time 1ms (GtG)
Viewing angle 178° (H) / 178° (V)
Curved Flat
Brightness 300
Contrast Ratio 1000:1
Adjustment (Pivot) N/A
Frameless Design Yes
Weight 4.2 kg / 5.6 kg
2.7 kg (without stand)
HDR Support N/A
PIP / PBP Function N/A
Adjustment (Height) N/A
Adjustment (Swivel) N/A
Power Type External Adaptor 12V 3A
Note
Display Port: 1920 x 1080 (Up to
180Hz)
HDMI™: 1920 x 1080 (Up to
180Hz)
Adobe RGB, DCI-P3 and sRGB
follow CIE1976 Standard
Adjustment (Tilt) -5° ~ 20°
Signal Frequency 55.3~200 KHz(H) /48~180 Hz(V)
Power Input 100~240V, 50/60Hz
VESA Mounting 75 x 75 mm
Kensington Lock Yes
Audio ports 1x Earphone out
Video ports 1x Display Port (1.2a)
2x HDMI™ (2.0b)
Display Colors 16.7M
Surface Treatment Anti-glare
Active Display Area (mm) 527.04(H) x 296.46(V)
DCR 100000000:1
Panel Type Rapid IPS
