- alimentación
- UPS Capacity600 VA / 360 W
- Entrada
- Input Voltage Range85 VAC to 150 VAC
- Input Frequency50/60 Hz self-adaptive
- Plug TypeType B (NEMA 5-15)
- Salida
- Rango de voltaje de salida110 VAC to 125 VAC
- Output Frequency50/60 Hz ± 0.5 Hz self-adaptive
- Transfer Time≤ 10 ms
- WaveformPWM
- Outlet TypeType B (NEMA 5-15)
- Outlet NumberBattery outlet*4 & Bypass*2
- batería
- Tipo de batería12 V/7 Ah, lead-acid battery
- Recharge Time4-6 hours recover to 90% capacity
- Typical Backup Time
Run time at 60w: 35 min
Run time at 100w: 20 min
Run time at 200w: 3 min
- Interfaz
- Communicate PortsNo
- Protección
- Full ProtectionSurge protection,Overload protection,Discharge protection,Overcharge protection
- indicador
- pantalla
LED indicator
Working Mode (AC Mode): Solid green
Charging Mode (DC Mode): Solid red
Overloading Mode: Flashing yellow
- Alarma
Charging Mode (DC mode): Sounding every 8 seconds
Low Battery: Sounding every second
Overloading Mode: Sounding every 0.5 seconds
Fault: Continuously sounding
